1. Setting and Display Unit Operation
1.5 Data Setting Method
I-13
1.5 Data Setting Method
(1) Outline of data setting
The data setting method consists
mainly of the following steps:
(1) Enter the data number.
(2) Move the cursor.
(3) Press data keys.
(4) Press the INPUT key.
When a screen is selected, the cursor
is displayed in the right end within the
first parentheses in the setting area.
RESERCH PLC-SW COM-VAR LOC-VAR MENU
[COMMON VARIABLE] MONITOR 7.1/11
# 110
100 -123456.7890 111
101 12.3456 112
102 113
103 114
104 115
105 116
106 117
107 118
108 119
109
#( )DATA( )NAME( )
Data setting
area
Curso
r
(1) Enter the data number.
Enter the number of the data to be set by
using the numeric keys.
(Example)
To set data in #104, press
1
0
4
.
RESERCH PLC-SW COM-VAR LOC-VAR MENU
#( 104 )DATA( )NAME( )
(2) Move the cursor.
To move the cursor to the next
parentheses, press the
key.
RESERCH PLC-SW COM-VAR LOC-VAR MENU
#( 104 )DATA( )NAME( )
(3) Press data keys.
Seeing the data display area contents,
enter new data by using the keys.
(Example)
To change to 12.345, press
1
2
3
4
5
.
RESERCH PLC-SW COM-VAR LOC-VAR MENU
#( 104 )DATA( 12.345 )NAME( )
(4) Press the INPUT key.
Check the setup contents displayed in the
setting area and set the data in memory by
pressing the
INPUT
key.
1) Data setting processing is performed
according to the setting area contents,
and the result is displayed in the data
display area.
2) The data number in the setting area is
incremented by one, and the cursor is
displayed in the right end within the
second parentheses.
After the last data number is input, it is
not displayed. At this time, the cursor is
displayed in the right end of the first
parentheses.
RESERCH PLC-SW COM-VAR LOC-VAR MENU
[COMMON VARIABLE] MONITOR 7.1/11
# 110
100 -123456.7890 111
101 12.3456 112
102 113
103 114
104 115
105 116
106 117
107 118
108 119
109
#( 105)DATA( )NAME( )
