1. Setting and Display Unit Operation
1.4 Screen Selection Procedure
I-9
1.4 Screen Selection Procedure
The following operation methods are based on using the exclusive setting and display unit.
Select a screen according to the following procedure:
(1) Select a function screen by using the appropriate function key.
(2) Select a menu screen in the function by using the appropriate menu key.
(3) Select a page in the menu screen by using the page key.
FUNCTION
MENU
Pa
g
e
First
page
Page Page
Menu 1
Menu 2
Menu 3 Menu 4 Menu 5 Menu 6
Menu 7
Menu 8
1.1
screen
2.1
screen
3.1
screen
4.1
screen
5.1
screen
6.1
screen
7.1
screen
8.1
screen
5.2
screen
6.2
screen
1.3
screen
6.3
screen
6.4
screen
4.2
screen
1.2
screen
2.2
screen
8.2
screen
Second
page
Third
page
Fourth
page
(1) Select a function screen.
MONI-
TOR
TOOL
PARAM
EDIT
MDI
DIAGN
IN/OUT
SFG
F0
Press the function selection key
corresponding to the function screen to be
displayed.
(Example)
Press the
MONI-
TOR
key.
1) The previously displayed menu screen is
displayed in the data display area.
2) The first display screen after power is turned
ON is the screen on the first menu.
If the same function selection key is again
pressed, a return is made to the first page
screen of the first menu.
(Example)
Again press the
MONI-
TOR
key.
POSI COORDI COMMAND SEARCH MENU
[PROGRAM SEARCH] MONITOR 4.1/4
O12345678 N12345-12
<SUB> O 1000 N 200-30
[PROGRAM FILE]
100 1500 50000 1234567
200 2000 70000 2000000
300 3000 123456 3000000
400 7000 200000 4000000
1234 10000 300000 5000000
[COL.BLOCK]
O N -
N20 G91 G28X0 Y0 Z0;
O( )N( )-( ) TAPE( )
[POSITION] 12/14 13:27 MONITOR 1
O12345678 N12345-12
<SUB> O 1000 N 200-30
S 12345
( 2000)
#1 T 1234
M 12
#1
Fc 12000.00
G00 X-345.67 Y345.67;
T1234;
N100 S5000 M3;
N200 G00 Z-100;
X -12345.678
Y 12345.678
Z 0.000
C 0.000
POSI COORDI COMMAND SEARCH MENU
