4. Operation Mode
4.5 Incremental Feed Mode
II-11
4.5 Incremental Feed Mode
The incremental feed mode enables the controlled axis to be moved at a given distance selected by using the
HANDLE/INCREMENTAL MAGNIFICATION switch at the manual feedrate when the FEED AXIS SELECT
switch is ON.
Operation procedure
Using the MODE SELECT switch, select the incremental feed mode.
Using the HANDLE/INCREMENTAL MAGNIFICATION switch set a travel distance.
The controlled axis selected by turning ON the FEED AXIS SELECT switch once is
moved at a given distance.
