6. Data In/Out
6.1 DATA INPUT
I-228
(3) Precaution for using 2-part system
When using the 2-part system, the machining program input operation can be switched with the
parameters.
#1050
MemPrg
#1285
ext21/bit0
#1286
ext22/bit0
Details
0, 2, 4, 6 - The input machining program is registered in the memory
common for the systems.
1, 3, 5, 7 OFF OFF The input machining program is registered in the memory for
the selected systems.
OFF ON The input machining program is registered in the memory for
the selected systems. If the system is not selected, an empty
(only EOR [%]) machining program is registered in the
memory.
ON OFF The input machining program is separated into machining
programs for each system at the $ mark, and is registered in
the memory for each system.
ON ON The input machining program is separated into machining
programs for each system at the $ mark, and is registered in
the memory for each system.
If the system does not have a $ mark, an empty (only EOR [%])
machining program is registered in the memory.
(Example) When parameter "#1050 MemPrg" is set to 1, 3, 5 or 7, and "#1286 ext22 bit0" is set to 1,
the file (tape) delimited into systems with the $ mark is separated and input for each
system.
E E E E E E E E E E
O O O1234 O $1 O N1 G28 X0 Y0 Z0 O N2 G00 X100. O N2 $2 O G28 X0 O O O
R B B B B B B B B R
Program body for System 1 Program body for System 2
