3. Tool Offset (L system)
3.6 Tool Registration
I
-110
Refer to "3 (II). Tool Offset (M system)" for M system.
(2) Executing the manual numeric command ..... Carry out this step after (1) above.
1) Press the address key corresponding to the command. The display area of the corresponding
command value is highlighted, and a manual numeric command input status results. Execute tool
function commands with
T
, and miscellaneous function commands with
M
.
2) Key-input the numerical value to be commanded.
3) Press the
INPUT
key. The command is executed.
(Note)
The manual numeric command operation is the same as the operation on the POSITION screen.
Refer to the section on manual numeric commands for the MONITOR and POSITION screens for
details.
(3) Operation for returning the mode from the manual numeric command mode to the normal data
setting mode
Press the
key. The normal data
setting mode returns.
T20 M6
MG( ) TOOL( ) D( ) AUX( )
1) The cursor appears in the first set of
parentheses, and the normal setting mode is
enabled.
