6. Operation Panel Switch Functions
6.16 Deceleration Check
II-34
6.16.4 Parameters
(1) Designation of deceleration check
Base specification parameters
# Items Details Setting range
inpos Change with the "#1306 InpsType deceleration check designation
type".
0: Deceleration check method
1: Validate in-position check
Deceleration
check
method 1
Select the G0 deceleration check method.
0: Command deceleration check
1: In-position check
0/1
1193
Validate
in-position
check
Designate the deceleration confirmation method for the
positioning and cutting command.
0: G0, G1+G9 Command deceleration check
1: G0, G1+G9 In-position check
0/1
1223 aux07
(bit1)
Deceleration
check
method 2
Select the deceleration check method for G1 + G9.
0: Command deceleration check when G1+G9
1: In-position check when G1+G9
Deceleration check is executed only for G1+G9.
If the #1306 InpsType deceleration check designation
type is "1" (deceleration check designation type 2), this
parameter will be invalid.
0/1
1306 InpsTyp Deceleration
check
specification
type
Select the parameter specification type for the G0 or G1
deceleration check.
0: Deceleration check specification type 1
G0 is specified with “#1193 inpos”, and G1+G9
with “#1223 aux07/BIT1”.
1: Deceleration check specification type 2
G0 or G1+G9 is specified with “#1193 inpos”.
0/1
(2) Deceleration check during opposite direction travel
Base specification parameters
# Items Details Setting range
1502 G0Ipfg
G1 → G0
deceleration
check
0: Do not perform a deceleration check when the
move direction is changed from G1 to G0.
1: Perform a deceleration check when the move
direction is changed from G1 to G0.
0/1
1503 G1Ipfg
G1 → G1
deceleration
check
0: Do not perform a deceleration check when the
move direction is changed from G1 to G1.
1: Perform a deceleration check when the move
direction is changed from G1 to G1.
0/1
