7. Diagnosis
7.10 Auxiliary Axis Monitor
I
-310
(b) Starting and stopping the operation
The following operation start and stop operations apply to the "JOG", "INCREMENTAL", and "MANUAL
OPERATION" modes.
After setting the mode with the operations described in item (a), the operation is started and stopped
using the following operation keys.
Function Operation key Details
Normal rotation
Operation key:
This starts the rotation in the forward
run direction. The rotation will stop if this
key is pressed while starting.
Reverse rotation
Operation key:
This starts the rotation in the reverse
run direction. The rotation will stop if this
key is pressed while starting.
Stop
Operation key:
Press any key other than
the SHIFT key.
(Example)
A
key
This stops the rotation during forward or
reverse run.
The operation is stopped and the operation adjustment mode is canceled if after starting, the screen is
changed from the AUXILIARY AXIS MONITOR screen to another screen, or the monitor axis is
changed.
The following table shows the relation between the various key operations and the operation start/
stop.
Operation status (status before key operation)
Key operation
Stop status
Forward run
status
Reverse run
status
Screen
change
FORWARD RUN
START
↑
key
Normal Stop Stop No change
REVERSE RUN START
↓
key
Abnormal Stop Stop No change
ALPHANUMERIC
CHARACTER key
Remain in stop
status
Stop Stop No change
CNC FUNCTION,
MENU KEY,
NEXT/PREVIOUS
PAGE key
Remain in stop
status
Stop Stop Change
→←
, TAB key, SHIFT,
CB, DEL, INPUT key,
MENU key, CYCLE
START, RESET key,
etc.
Remain in stop
status
Remain in
forward run
status
Remain in
reverse run
status
No change
(Note 1)
CNC axis handle movement is invalid in the MR-J2-CT handle mode.
The No. 1 handle is fixed for the MR-J2-CT handle mode.
