6. Daily Maintenance and Periodic Inspection and Maintenance
6.3 Replacement Methods
III-50
(2) Method for disassembling the cassette cover
R
L
MEMORY CASETTE Ver.*
FCU6-HR4** SER.9801001
Installation guides
Case B
Case A
Memory card Name label
Push
1) Remove the name label holding case A and B.
2) Press the indented area on case B and separate the case into parts A and B.
3) Remove the memory card inside from the installation guides.
Incorrect connections may damage the devices, so connect the cables to the specified
connectors.
Do not replace the memory cassette while the power is ON.
Do not connect or disconnect the connection cables between each unit while the power
is ON.
Be careful that metal cutting chips, etc., do not come into contact with the connector
contacts of the memory cassette.
CAUTION
