7. Diagnosis
7.11 MELDASNET Support Parameters
I
-312
Main item # Item Details
Setting
range
STATE – Sampling The sampling execution state is displayed.
"sampling" : Sampling is being executed.
"sampling stop" : Sampling is stopped.
"sampling invalid" : The MELDASNET function is
invalid.
–
1 Sampling Restart of sampling is designated.
0: Sampling is restarted.
0 OPE
2 Sampl.
data clear
Sampling is stopped, and the sampled data is cleared.
1: The sampled data is cleared.
#(1)( 1) INPUT
↓
Clear? (Y/N)
↓ ↓
To clear sampled data
Y INPUT
"Data clear complete"
appears
To not clear sampled data
N INPUT
(Note)
Sampling will stop when the sampling data clear
operation is executed. To restart sampling, the
restart sampling operation will be executed or the
power must be turned ON again.
1
Designate the system that is not to be sampled.
Set the system with a bit unit.
76543210
bit
S
y
stem 1
S
y
stem 2
5 System
The entire system will be sampled when 0 is set.
Set
with a
HEX.
Designate the spindle that is not to be sampled.
Set the spindle with a bit unit.
bit
76543210
2nd s
p
indle
1st s
p
indle
6 Spindle
The entire system will be sampled when 0 is set.
Set
with a
HEX.
Designate the axis that is not to be sampled.
Set all servo axes with a bit unit regardless of the system.
bit 76543210
6th axis
5th axis
4th axis
3rd axis
2nd axis
1st axis
SAMPLING
SPEC
7 Servo
The entire system will be sampled when 0 is set.
Set
with a
HEX.
