2. Monitor
2.3 COMMAND
I-45
2.3.2 Execution Modal Monitor
By switching the screen from the execution program's monitor screen (in the previous section) by
using the
NEXT
PAGE
key, the execution modal's monitor screen is displayed. This screen mainly
displays the modal
values of the active machining program for monitoring.
[M system] [L system]
POSI COORDI COMMAND SEARCH MENU
[MODAL INFORM.] MONITOR 3. 2/3
O12345678 N 12345-12 [WORK]
<SUB> O
1000 N 200-30 X1 100.000
G00 G18 G90 G94 Y1 200.000
G21 G80 G98 G15 G64 Z1 300.000
G67 G40.1 G97 G50.1 G43.1 A1 0.000
G68 :R= B1 0.000
G51 :P= G54 : C1 0.000
G40: D =
G49: H = G05
: H = :P10000
FA 24000.00 S 12345 M 123454678
FM 1200.00 10
FS 0.0000 T 1234 35
B 1234 40
G28X0Y0Z0;
LSK mm ABS G40 G54
POSI COORDI COMMAND SEARCH MENU
[MODAL INFORM.] MONITOR 3. 2/3
O12345678 N 12345-12 [WORK]
<SUB> O
1000 N 200-30 X1 100.000
G00 G18 G G23 G98 Z1 200.000
G21 G40 G80 G C1 300.000
G64 G67 G69 U1 0.000
G97 G14 G13.1 G43.1 V1 0.000
W1 0.000
G54 : Tx: -12.345
Tg: 12 Tw:12 Tz: 12.345
V 0 Tc: 10.000
FA 24000.00 S 12345 M 123454678
FM 1200.00 10
FS 0.0000 T 1234 35
FE 0.0000 B 1234 40
G28X0Z0C0;
LSK mm ABS G40 G54
Display item Explanation
O12345678 N12345-12 The currently executing program number, sequence number, and
block number are displayed.
<SUB> O1000
N200-30
When a subprogram is being executed, the program number,
sequence number, and block number of the subprogram are
displayed.
[WORK]
X1 100.000
Y1 200.000
Z1 300.000
:
The workpiece coordinates in the workpiece coordinate system
being currently executed are displayed.
Same as the POSITION screen.
[MODAL INFORM.]
G00..........G94
G67.......G43.1
The modal state of the current G command being executed is
displayed.
(Note) Fixed cycle operation:
When a fixed cycle command is executed, the G command
in the fixed cycle control subprogram does not reflect the
G modal of the calling program.
G40:D
G49:H
The tool radius compensation modal and offset number and wear
amount are displayed.
The tool length offset modal and offset number and wear amount
are displayed.
