2. Monitor
2.4 PROGRAM SEARCH
I-48
2.4 PROGRAM SEARCH
When the menu key
SEARCH
is pressed, the PROGRAM SEARCH screen is displayed.
The SEARCH screen enables you to call the program number, sequence number, and block number for
automatic operation from the machining programs registered in memory (or on paper type).
POSI COORDI COMMAND SEARCH MENU
[PROGRAM SEARCH] MONITOR 4. 1/4
O 12345678 N 12345-12
<SUB> O 1000 N 200-30
[PROGRAM FILE]
100 1500 50000 1234567
200 2000 70000 2000000
300 3000 123456 3000000
400 7000 200000 4000000
1234 10000 300000 5000000
[COLLATION BLOCK]
O N -
O( ) N( )-( ) COL.( ) TAPE(0)
$1
Display item Explanation
O12345678 N12345-12 The currently executing program number, sequence number, and
block number are displayed.
<SUB>
O 1000 N 200-30
When a subprogram is being executed, the program number,
sequence number, and block number of the subprogram are
displayed.
[PROGRAM FILE]
100 1500 50000 1234567
200 2000 70000 2000000
300 3000 123456 3000000
400 7000 200000 4000000
1234 10000 300000 5000000
The numbers of the machining programs registered in memory are
listed.
The numbers ranging from 1 to 99999999 are displayed in the
ascending order.
If the number of the registered programs exceeds one page of
display, PROGRAM FILE is displayed extending across pages.
[COLLATION BLOCK]
O N -
The program position for compare stop is displayed.
After MDI operation is executed, programs cannot be searched for unless reset is executed.
To restart from the middle of the program, search for the restart block, and then carry out MDI operation to
restore the modal state.
(Note 1) When using the 2-part system, the system name of the currently selected system is displayed as
$1 (system 1) and $2 (system 2). This is not displayed when using a 1-part system. (Only L
system)
(Note 2) When using the 2-part system, the details displayed in the list of machining program numbers can
be switched with the parameters.
#1050 MemPrg Details
0, 2, 4, 6
The numbers of the machining programs registered in the memory
common for the systems are listed.
1, 3, 5, 7
The numbers of the machining programs registered in the memory for the
selected system are listed.
