2. Monitor
2.1 POSITION
I-20
2.1 POSITION
When the menu key
POSI
is pressed, the POSITION screen is displayed.
POSI COORDI COMMAND SEARCH MENU
[POSITION] 12/14 13:27 MONITOR 1
O12345678 N12345-12
<SUB> O 1000 N 200-30
S 12345
( 2000)
#1 T 1234
M 12
#1
Fc 12000.00
G00 X-345.67 Y345.67;
T1234;
N100 S5000M3;
N200 G00Z-100.;
X -12345.678
Y 12345.678
Z 0.000
C 0.000
(4-axis pecifications)
The following can be performed on the POSITION screen:
(1) Full screen erase
(2) Origin set. The current value (POSITION) data of each axis can be set to 0.
(3) Manual numeric command. Miscellaneous function output of M, S, T, etc., can be set through the
screen.
