2. Monitor
2.3 COMMAND
I-44
2.3 COMMAND
When the menu key
COMMAND
is pressed, the COMMAND screen is displayed.
This screen consists of three pages. It displays the execution program monitor, execution modal
monitor,
and cumulative time data. Page switching is by pressing the
NEXT
PAGE
key or
PREVIOUS
PAGE
key.
2.3.1 Execution Program Monitor
This screen displays the active machining
program's execution blocks for monitoring.
POSI COORDI COMMAND SEARCH MENU
[COMMAND] MONITOR 3.1/3
O12345678 N12345-12 [WORK]
<SUB> O 1000 N 200-30 X 100.000
Y 200.000
Z 300.000
C 0.000
N10 ......... ;
N20 ............ ;
N30 ;
N40 ;
N50 ;
N60 ;
N70 ;
N80 ;
N90 ;
N100 ;
Display item Explanation
O12345678 N12345-12 The currently executing program number, sequence number, and
block number are displayed.
<SUB> O1000
N200-30
When a subprogram is being executed, the program number,
sequence number, and block number of the subprogram are
displayed.
N10 ......... ;
N20 ............ ;
N30 ;
N90 ;
N100 ;
The current program being executed is displayed.
The cursor is moved to the top of the current block being executed.
When program execution reaches N90, the cursor is also moved to
the top of N90.
When the N100 block is executed, the N100 block is displayed
starting at the top of the screen and the cursor is also moved to the
top.
The read data is displayed also during tape running in the above
way.
[WORK]
X 100.000
Y 200.000
Z 300.000
C 0.000
The workpiece coordinates in the workpiece coordinate system
being currently executed are displayed.
