6. Data In/Out
6.4 PROGRAM COPY
I-259
6.4.2 Machining Program Condense
The storage efficiency of the machining programs registered in memory may be lowered when correction
such as data deletion or addition is made. When memory is used wastefully, the condense function can be
used to move the intermediate blank portions forward and increase the remaining number of characters that
can be registered.
Set 2 in # ( ) for the condense command. To execute the condense function for all machining programs
registered in memory, set ALL in first 0 ( ).
Press the
INPUT
key.
To condense all work programs
registered in memory
# (2)
O (ALL)
→
O ( )
# (2) O ( ALL)
→
O( )
CONDENSE EXECUTIN
# (2) O ( ALL)
→
O( )
CONDENSE COMPLETE
# ( ) O ( )
→
O( )
1) Condense is started and the message
"CONDENSE EXECUTION" is
displayed in the message field.
2) The time required for condense varies
depending on the total number of the
registered machining programs. Do
not turn off the NC power during
condense execution.
(Note 1) When using the 2-part system, the machining program condense operation can be switched with
the parameters.
#1050
MemPrg
#1285
ext21/bit0
Details
0, 2, 4, 6 - Of the machining programs registered in the memory common for the
systems, the designated machining program is condensed.
1, 3, 5, 7 OFF Of the machining programs registered in the memory for the selected
systems, the designated machining program is condensed.
ON Of the machining programs registered in the memory for each system, the
designated machining program is condensed.
(Note 2) When using the 2-part system and the same number batch generation for all system programs is
valid, an error (E14) will occur if the all system condense program is not found.
(Note 3) When using the 2-part system and the same number batch generation for all system programs is
valid, the programs cannot be condense in a system that does not have the condense program.
(Note 4) When using the 2-part system, and ALL is set, all machining programs registered in the memory
for all systems will be condensed.
