7. Diagnosis
7.3 SPINDLE MONITOR
I-281
Display item Explanation
Control input 1 Control input signal from control unit
F E DCBA9876543 2 1 0
In G1 modal
Torque limit mode
Servo alarm reset command
Parameter conversion command
Servo ON command
Ready ON command
Control input 2 Control input signal from control unit
Control input 3 Control input signal from control unit
F E DCBA9876543 2 1 0
Sub-motor selection command
0:Main motor 2: Sub motor2
1:Sub motor1 3: Sub motor3
L winding selection command
Orient start
Indexing reverse run
Indexing forward run
Reverse run start command
Forward run start command
Gear selection
command
Spindle control mode
selection command
0: No. 1 gea
r
1: No. 2 gear
2: No. 3 gear
3: No. 4 gear
4: No. 5 gear
5: No. 6 gear
6: No. 7 gear
7: No. 8 gear
