4.1 Workpiece Coordinate
I-132
4.1 Workpiece Coordinate
Pressing the menu key
WORK
displays the WORK OFFSET screen.
The workpiece coordinate system offset data can be set or displayed for the number of axes.
[WORK OFFSET] TOOL 5. 1/1
#A: ABS. #I: INC.
<X> <Y> <Z> <C>
[MACHINE] 0.000 0.000 0.000 0.000
[TLM] 0.000 0.000 0.000 0.000
#
54 G54 0.000 0.000 0.000 0.000
55 G55 0.000 0.000 0.000 0.000
56 G56 0.000 0.000 0.000 0.000
57 G57 0.000 0.000 0.000 0.000
58 G58 0.000 0.000 0.000 0.000
59 G59 0.000 0.000 0.000 0.000
60 EXIT 0.000 0.000 0.000 0.000
# ( ) DATA ( ) ( ) ( ) ( )
WORK PROCESS I/O PAR SETUP MENU
[When workpiece position measurement specifications are added (M system)]
[WORK OFFSET] TOOL 5. 1/18
#A:ABS. #I:INC.
<X> <Y> <Z> <C>
MACHINE 1.234 -10.987 5.000 0.000
TLM 0.000 0.000 0.000 0.000
#
54 G54 0.000 0.000 0.000 0.000
55 G55 0.000 0.000 0.000 0.000
56 G56 0.000 0.000 0.000 0.000
60 EXT 0.000 0.000 0.000 0.000
#1 TLM P.A 0.000 0.000
#2 TLM P.B 0.000 0.000
#3 TLM P.C 0.000 0.000
WLM
#( 1) DATA ( ) ( ) ( ) ( ) ( ) ( )
LSK mm INC G40 G54 MEMORY
WORK PROCESS I/O PAR SETUP MENU
