11. Visual Analyzer (Waveform display)
11.1 Menu Function
I
-373
11.1 Menu Function
Menu Function
SINGLE
When menu key
SINGLE
is pressed, data is collected and displayed for "#1 setting
value
∗
12 scale [ms]".
AUTO
When menu key
AUTO
is pressed, data is continuously collected and displayed.
DISPLAY The waveform data last page is displayed.
(Note 1)
For continuous waveform display, the waveform display stop condition can be selected using
#10.
(Note 2)
To refer to data exceeding one screen with the continuous waveform display, press the menu
key
AUTO
to stop the waveform display, and then press the page key.
(Note 3)
The parameter settings cannot be changed during continuous waveform display. Stop waveform
display and change them.
(Note 4)
The data for up to 4226 points can be retrieved for the waveform data. If data exceeding 4226
points is retrieved, the data will be deleted from the oldest data.
