Appendix 7.
Operation Messages on Setting and Display Unit
IV-25
Error No. Error message Details
E06 NO SPEC
×
• The menu key for a function not in the specifications was
pressed.
• A parameter not in the specifications was set.
• A language that was not added as an option was selected.
(#1043 lang)
• Set up parameter #1049 mmac_R was set to “1” when the
machine manufacturer macro option was not valid.
• Set up parameter #1060 SETUP was set to “20” when the
machine manufacturer macro option was not valid.
• Writing of the machine manufacturer macro program with the
PROGRAM COPY screen was attempted when the machine
manufacturer macro option was not valid.
E07 RESET END
∆
• The input/output operations were forcibly stopped by reset‚ etc.
(including EMG).
E08 PHYSICAL ERR
×
• The input/output parameter setting or input/output unit side
setting was incorrect.
E09 TIME OUT
×
• The input/output unit parameter “#9116 TIME-OUT SET” setting
was too short.
• There is no EOB code in the machining program.
E10 MEMORY OVER
×
• The program cannot be written because the memory capacity is
exceeded.
• This error occurs when the MDI data setting on the MDI screen
exceeds 500 characters‚ or when saving MDl‚ editing or making a
program on the edit screen‚ input on the data input/output screen‚
program copy‚ etc.
E11 PROG. No. DUPLI
∆
• When registering a machining program in the memory‚ a program
with the same No. as the designated program No. was found in
the memory. Refer to the program file to find a program No. not
being used‚ and reset the program No.
• A program with the same No. as the machining program to be
copied from the memory was found in the IC card.
• This error occurs during MDI registration in the MDI screen or
during creation of a program in the edit screen.
E12 FILE ENTRY
OVER
×
• When registering a machining program in the memory‚ the No. of
programs determined in the specifications is exceeded‚
preventing registration.
This error occurs during MDI registration in the MDI screen‚
creation of a program in the edit screen‚ data input in the data
input/output screen‚ and program copy.
E13 NB NOT FOUND
∆
• The block with the designated sequence No. or block No. does
not exist in the designated program.
E14 PROG. NOT
FOUND
∆
• The designated program is not found in the memory.
• The corresponding program No. was not found with search of
tape memory during graphic check.
