6.2 DATA OUTPUT
I-235
6.2 DATA OUTPUT
Pressing the menu key
OUTPUT
displays the DATA OUTPUT screen.
The DATA OUTPUT screen allows the operator to output user-created machining programs (main program
and subprogram), tool offset data, parameters, common variables and history data that have been stored in
memory.
[DATA OUTPUT] IN/OUT 2
<LOCK>
# 1 MAIN PROGRAM
# 2 TOOL DATA OFF #11 PORT No.2
# 3 PARAMETER OFF #12 DEVICE No.1
# 5 COMMON VARI OFF (FDD:9600bps)
#30 MACRO PROGRAM #28 AUX-PARA
#60 TRACE DATA
#99 MAINTENANCE
<OUTPUT DATA>
#( ) DATA( ) ( )
INPUT OUTPUT ERASE FILE MENU
$1
(Note 4)
# Item Explanation
1 MAIN PROGRAM (Note 1) The types of data that can be output are as follows.
(1) Used to output a machining program.
2 TOOL DATA
(2) Used to output tool data.
3 PARAMETER
(3) Used to output parameter data.
5 COMMON VARIABLE
(4) Used to output a common variable.
28 AUX-PARA
(5) Used to output an auxiliary axis parameter data.
30 MACRO PROGRAM
(6) Used to output a macro program.
60 TRACE DATA (7) Used to output history data.
11 PORT NO. The I/O port number and device number required to output data
are set.
12 DEVICE NO.
If they are already set on the I/O BASE PARAM screen, the setup
values are displayed on the DATA OUTPUT screen. They may
be changed on either screen.
(Note 1) To output a fixed cycle program, set the parameter.
Refer to the Appendix "Registration and editing of fixed cycle programs".
(Note 2) If the data protection, edit lock B, or edit lock C condition is set, data may not be output. For the
details, see the descriptions in "Data protection" and "Edit lock" in Section 6.7.
(Note 3) The screen cannot be changed during data output.
Output inhibit
condition
Output method
Data protection key on
Machining programs,
tool data, parameters
Edit lock B on
Machining programs
8000 to 9999
Edit lock C on
Machining programs
9000 to 9999
Specifying individual
machining programs
No data is output. Machining programs
O8000 to 9999 are not
output.
Machining programs
O9000 to 9999 are not
output.
Specifying ALL
Specifying a range
No data is output. Machining programs
other than O8000 to
9999 are output.
Machining programs
other than O9000 to
9999 are output.
(Note 4) When using the 2-part system, the system name of the currently selected system is displayed as
$1 (system 1) and $2 (system 2). This is not displayed when using a 1-part system. (Only L
system)
