2. Monitor
2.2 COORDINATE
I-41
Press the
key.
N130 G02 X150.0 Y150.0 I0.0 J25.0;
N140 G02 X200.0 Y150.0 I25.0 J0.0;
N150 G02 X200.0 Y200.0 I0.0 J25.0;
N160 G02 X250.0 Y200.0 I25.0 J0.0;
N170 G02 X250.0 Y250.0 I0.0 J25.0;
N175 G74 Z-10.0 R;
BUFFER EDIT
Insert "–5.0P2.0" at the end of the
N175 line.
N130 G02 X150.0 Y150.0 I0.0 J25.0;
N140 G02 X200.0 Y150.0 I25.0 J0.0;
N150 G02 X200.0 Y200.0 I0.0 J25.0;
N160 G02 X250.0 Y200.0 I25.0 J0.0;
N170 G02 X250.0 Y250.0 I0.0 J25.0;
N175 G74 Z-10.0 R-5.0 P2.0;
BUFFER EDIT
Press the
INPUT
key.
N120 G02 X150.0 Y100.0 I25.0 J0.0;
N130 G02 X150.0 Y150.0 I0.0 J25.0;
N140 G02 X200.0 Y150.0 I25.0 J0.0;
N150 G02 X200.0 Y200.0 I0.0 J25.0;
N160 G02 X250.0 Y200.0 I25.0 J0.0;
N170 G02 X250.0 Y250.0 I0.0 J25.0;
N175 G74 Z-10.0 R-5.0 P2.0;
N180 G02
X
300.0 Y250.0 I25.0 J0.0;
(i) If an error occurs in the preread block and the buffer correction mode is entered, the block in
which the error occurred will appear at the head of the area.
(j) The error cannot be canceled for a fixed cycle or compound fixed cycle that cannot be displayed.
Programs that cannot be displayed include:
• Fixed cycles
• Compound fixed cycles
• Machine maker macros (when base specification parameter #1166 fixpro=0)
• When running program No. 9000 to 9999 while the program display lock is valid (base
specification parameter #1122 pglk_c=1).
(k) When the program area selection (base specification parameter #1050 MemPrg) is set to 0
[program system same control specifications] and programs with the same numbers are run for
the two systems, the buffer cannot be corrected. The message "CAN'T BUF. EDIT" will appear.
